D Series 4 * 2 Light Duty Commercial Trucks D1 & D2 & D3 Flatbed Small Cargo Truck

Ask Lasest Price
Brand Name :	CIVL
Model Number :	CIVL
Certification :	ISO,CCC
Delivery Time :	Within 35 days

Add to Cart

Product Details
Company Profile

D Series 4 * 2 Light Duty Commercial Trucks D1 & D2 & D3 Flatbed Small Cargo Truck

Specifications

Model		FD1030D12K-3	FD1030P12K-3	FD1032P12K-2	FD1040P12K-3
Fuel Type		Diesel	Diesel	Diesel	Diesel
Cabin		1700mm single row	1700mm, one and a half seat	1700mm, one and a half seat	1700mm, one and a half seat
Main dimensions	Overall demension (L×W×H)mm	5485×2000×2250	5485×2000×2250	5495×2000×2250	550020002250
	Demension of the cargo body(L×W×H)mm	3480×1810×400	3280×1810×400	3280×1810×400	34801810400
	Driving Type	4×2	4×2	4×2	4*2
	Wheel base(mm)	2850	2850	2850	2850
Weight Data	Curb weight (kg)	2160	2160	2100	2160
	Rated payload(kg)	2000	2000	2000	2500
	Persons in cab	2	2	2	2
	Gross vehicle weight(kg)	4290	4290	4330
Main Performance	Max speed(km/h)	90	90	100	90
Main Performance	Min.turning of radius(m)	6	6	6.3	6
Engine	Model	FAW485	FAW485	QC490Q	QC485
	Type	In-line, Water-cooled, Four cylinder, Direct injection	In-line, Water-cooled, Four cylinder, Direct injection	In-line, Water-cooled, Four cylinder, Direct injection	In-line, Water-cooled, Four cylinder, Direct injection,Normally Aspirated Euro1
	Displacement(L)	2.27	2.27	2.67	2.156
	Rated power(KW)	36	36	45.6	36
Rear axle		1030type, ratio5.833	1030type, ratio5.833	1030type, ratio5.833	1030/5.833
Wheels and tyre size		6+1/6.50-16	6+1/6.50-16	6+1/6.50-16	6+1/7.00-16
Functional Configuration
warm braw		√	√	√	√
Adjustable steering wheel		√	√	√	√
Power steering		√	√	√	√
Exhaust brake		×	×	×	×
Preheat		×	×	×	×
fairwater cone		√	√	√	√
Air-conditioning		×	×	×	×
Clutch booster		√	√	√	√
electric control		×	×	×	×
Air valve		×	×	×	×
disc brake		○	○	○	○
anti-lock braking system		×	×	×	×
√ : Standard Equipment equipamiento de estandar○: Optional opcional ×: Not develop no desarrollo
Price(USD)

Brand		D2
Basic Information	Cabin	Extended
	Wheelbase(mm)	3800
	Overall demensionmm(mm)	6910×2200×2550
	Cargo Inner Demension(mm)	4665×2010×500
	Min.Ground clearance(mm)	185
	Rated payload(Kg)	6000
	GVW(Kg)	185
	Max.speed(km/h)	3620
Engine&Transmission	Fuel Type	Diesel
	Emission	EuroII
	Engine type	Yunnei4102
	Rated power(KW/rpm)	85/3000
	Max.torque(N.m/rpm)	320/2000-2200
	Steering system	Power assisted steering
	Transmission model	5MT
	Transmission model	530H
Brakes&Tyres	Service brake	Air brake
	Parking brake	Air-cut brake
	Auxiliary brake	Exhaust Brake
	Tyres model	8.25-16
Equipment	Heater	S
	Adjustable steering wheel	S
	Power steering	S
	Exhaust brake	S
	Preheat	S
	Air deflector	○
	Air-conditioning	-
	Clutch booster	S
	Electric control window	○
	SABS	-
	Disc brake	-
	ABS	-
S:Standard ○:Under developed -:Undeveloped

Brand		D3	D3	D3	D3
Basic Information	Cabin	Extended
	Wheelbase(mm)	4360	4500	4700	5100
	Overall demensionmm(mm)	7610/7880×2200 /2300×2450	8050×2300×2500	7995×2450×2570	8977×2500×2710
	Cargo Inner Demension(mm)	5460/5660×2000 /2100×500	5860×2100×500	5810×2260×500	6700×2300×600
	Min.Ground clearance(mm)	206	206	206	213
	Rated payload(Kg)	8000/7000	9000	9000	12000
	GVW(Kg)	12195/11575	13495/15595	13895	18595
	Max.speed(km/h)	100/90	90/100	95	107
Engine& Transmission	Fuel Type	Diesel	Diesel	Diesel	Diesel
	Emission	EuroII	EuroII	EuroII	EuroII
	Engine type	Yunnei4102	Xichai4102	Yuchai4108	Weichai4102
	Rated power(KW/rpm)	85/3000	81/2900	100/2700;96/2800	105/2800
	Max.torque (N.m/rpm)	320/2000~2200	310/1800	380/1600-1900	430/1400-1800
	Steering system	Power assisted steering	Power assisted steering	Power assisted steering	Power assisted steering
	Transmission model	5MT	5MT	4MT	4MT
	Transmission model	548H	548H	845	885S
Brakes& Tyres	Service brake	Air brake	Air brake	Air brake	Air brake
	Parking brake	Air-cut brake	Air-cut brake	Air-cut brake	Air-cut brake
	Auxiliary brake	-	-	-	-
	Tyres model	8.25-16	8.25-16	8.25-20	10.00-20
Equipment	Heater	S	S	S	S
	Adjustable steering wheel	S	S	S	S
	Power steering	S	S	S	S
	Exhaust brake	S	S	S	S
	Preheat	S	S	S	S
	Air deflector	○	○	○	○
	Air-conditioning	○	-	-	-
	Clutch booster	S	S	S	S
	Electric control window	○	○	○	○
	SABS	-	-	-	-
	Disc brake	-	-	-	-
	ABS	-	-	-	-
S:Standard ○:Under developed -:Undeveloped
